TelegramNetwork switch Cisco SG350X-48-K9-EU Тип - управляемый 3-го уровня, форм-фактор - в стойку, количество портов - 54, порты - SFP+, Gigabit Ethernet, комбинированный, возможность удаленного управления - управляемый, коммутационная способность - 176 Гбит/ с, размер таблицы МАС-адресов - 64000 Кб, корпус - Металический, 48x10/ 100/ 1000TX, 2хSFP+ D-Link DGS-1210-28MP/F1A
Invoice with VAT 20%
Address delivery «Nova Posta»
Courier in Kiev 1 ₴ Specifications:
| Hardware | ||
| Hardware version | • E1 | |
| The size | • Installation in a 19-inch rack • Height 1U | |
| Interfaces | • 24 10/100 / 1000Base-T ports with PoE support • 4 1000Base-X SFP ports | |
| Indicators | • Link / Activity / Speed (on 10/100/1000 Mbit / s port) • Power Fail / Power Ok (per PoE port) | |
| Network cables | • UTP categories 5, 5e (max. 100 m) | |
| Functional | ||
| Standards and functions | • IEEE 802.3 10Base-T (copper twisted pair) • IEEE 802.3u 100Base-TX (copper twisted pair) • IEEE 802.3ab 1000Base-T (copper twisted pair) • IEEE 802.3az Energy Efficiency Ethernet • Automatic matching speed and duplex mode • IEEE 802.3x flow control • IEEE 802.3z 1000Base-X • Automatic MDI / MDIX detection on all copper ports | |
| Duplex mode | • Half / full duplex for 10/100 Mbps speed • Full duplex for speed 1000 Mbps | |
| Performance | ||
| Switching matrix | • 56 Gbit / s | |
| Switching method | • Store-and-forward | |
| Max. 64-byte packet forwarding rate | • 41.7 Mpps | |
| MAC table size | • 16K records | |
| Packet buffer | • 1.5 MB | |
| RAM size | • 256 MB | |
| Flash memory | • 32 MB | |
| Software | ||
| Level 2 Functions | • MAC Address Table - 16K records • Static MAC Addresses - 256 records • IGMP Snooping - IGMP v1 / v2 Snooping - Supports up to 256 IGMP groups - Supports up to 64 static multicast groups - IGMP on VLAN - Supports IGMP Snooping Querier • Loopback Detection feature • 802.3ad Link Aggregation: max. 14 groups per device / 8 ports per group • LLDP • LLDP-MED • Jumbo frames - Up to 9216 bytes • Spanning Tree Protocol - 802.1D STP - 802.1w RSTP - 802.1s MSTP • Flow control - 802.3x - Prevent blocking HOL • Port Mirroring - One-to-One - Many-to-One - Supports mirroring for inbound / outbound / traffic in both directions • Multicast filtering - Redirect all unregistered groups - Filter all unregistered groups • Customizable MDI / MDIX interface - MLD snooping v1 / v2 (256 groups) | |
| VLAN | • 802.1Q • VLAN groups: - Max. 256 static VLAN groups • VID Range: 1-4094 • Asymmetric VLAN • Auto Voice VLAN - Max. number of user-defined OUI: 10 - Max. default OUI number: 8 • Auto Surveillance VLAN | |
| Quality of Service (QoS) | • 802.1p • 8 queues per port • Queue processing mechanisms: - Strict - Weighted Round Robin (WRR) • Bandwidth Management - Based on the port (inbound / outbound, with a minimum step of 64 Kbps for 10/100/1000 Mbps) • QoS based on: - 802.1p priority queues - DSCP - tos - IPv6 traffic class - TCP / UDP port numbers | |
| Level 3 functions | • IP interface - Support 1 interface • IPv6 Neighbor Discovery (ND) • Static routing - Max. 64 static IPv4 route entries - Max. 32 static IPv6 route entries | |
| Access Control Lists (ACLs) | • Max. number of access lists: 50 • Max. number of rules for IPv4, MAC and IPv6: 768 • Each rule can be tied to one port. • ACL based on: - 802.1p priority queues - VLAN - MAC addresses - Ether type - IP addresses - DSCP - Protocol type - TCP / UDP port numbers - IPv6 traffic class | |
| Security | • Broadcast / multicast / unicast storm protection • D-Link Safeguard Engine • DHCP Server Screening • IP-MAC-Port Binding (Intelligent Binding) - Supports 512 bind entries - Inspection of ARP packages - Inspection of ARP-packages + IP-packages - DHCP snooping • 802.1X port-based access control • Prevent ARP Spoofing Attacks - Max. number of records: 64 • Traffic segmentation • SSH v2 • SSL - Support v1 / v2 / v3 • Port Security - Supports up to 64 MAC addresses per port • Duplicate Address Detection (DAD) | |
| Oam | • cable diagnostics • Restore factory default settings | |
| AAA | • 802.1X authentication: - Local base / RADIUS server support - Supports Port Based Access Control - Supports EAP, OTP, TLS, TTLS, PEAP • RADIUS server with IPv6 support • MD5 authentication support | |
| Control | • Web interface • D-Link Network Assistant Utility • Simplified CLI • Telnet server • TFTP client • MDI / MDIX configuration • SNMP - Support v1 / v2c / v3 • SNMP Trap • Backup / Update Software • Smart Wizard Installation Wizard • Download / download configuration file • System log - Max. number of journal entries: 500 • BootP / DHCP client • SNTP • ICMPv6 • IPv4 / v6 Dual Stack • Automatic DHCP configuration • Time setting - SNTP • RMONv1 • Trusted Host • Support for multiple software versions | |
| Green V3.0 technology | • Energy savings due to: - Connection status definitions - Scheduled PoE: Turn off / on PoE ports on schedule - Turn off indicators - Use sleep mode - Turn off ports | |
| MIB / RFC Standards | • RFC 783 TFTP • RFC 951 BootP / DHCP Client • RFC 1157 SNMP v1, v2, v3 • RFC 1213 MIB II • RFC 1215 MIB Traps Convention • RFC 1350 TFTP • RFC 1493 Bridge MIB • RFC 1769 SNTP • RFC 1542 BootP / DHCP Client • RFC 1901 SNMP v1, v2, v3 • RFC 1907 SNMP v2 MIB • RFC 1908 SNMP v1, v2, v3 • RFC 2131 BootP / DHCP Client • RFC 2138 RADIUS Authentication • RFC 2139 RADIUS Authentication • RFC 2233 Interface Group MIB • RFC-2246 SSL • RFC 2475 • RFC 2570 SNMP v1, v2, v3 • RFC 2575 SNMP v1, v2, v3 • RFC 2598 CoS • RFC 2618 RADIUS Authentication • RFC 2819 RMON v1 • RFC 2865 RADIUS Authentication • RFC 3164 System Log • RFC 3195 System Log • RFC 3411-17 SNMP • D-Link Private MIB • LLDP MIB • Zone Defense MIB • 2233 Interface Group MIB | |
| Poe | ||
| PoE standard | • IEEE 802.3af • IEEE 802.3at | |
| PoE Ports | • Ports 1-24 | |
| PoE Power Budget | • 370 W (max. 30 W per PoE port) | |
| Physical parameters | ||
| Dimensions (L x W x H) | • 440 x 250 x 44 mm | |
| Weight | • 3.86 kg | |
| terms of Use | ||
| Nutrition | • 100-240 V AC, 50-60 Hz, internal universal power supply | |
| Max. power consumption | • 454.4 W (PoE enabled) • 33.1 W (PoE off) | |
| Standby power consumption | • 100 V: 23.4 W • 240 V: 21.8 W | |
| Heat dissipation | • 1,552.32 BTU / h | |
| MTBF (hours) | • 271 281 | |
| Noise level | • At low fan speed: 47.94 dB • With high fan speed: 52.41 dB | |
| Ventilation system | • 3 Smart fans | |
| Temperature | • Working: -5 to 50 ° C • Storage: -20 to 70 ° C | |
| Humidity | • During operation: from 0% to 95% non-condensing • Storage: 0% to 95% non-condensing | |
| Contents of delivery | ||
| • Switch DGS-1210-28MP • Power cable • Power cable retainer • 4 rubber feet • 2 mounting brackets for 19-inch rack mounting • Installation kit • Quick Installation Guide • CD | ||
| Other | ||
| Certificates | • CE Class A • VCCI Class A • FCC Class A • BSMI • CCC • C-Tick • cUL | |
| В наявності | Так |
| Manufacturer | D-Link |
| Type of | Customizable (smart) |
| Number of ports Fast Ethernet | Not |
| Number of ports Gigabit Ethernet | 24 pcs |
| Number of ports 2.5G Ethernet | Not |
| Number of ports 10G Ethernet | Not |
| Number of ports SFP | 4 things |
| Number of ports SFP+ | Not |
| Number of ports SFP28 | Not |
| Number of ports QSFP+ | Not |
| Number of ports supported PoE | 24 pcs |
| Special features | Rack mountable |
| Warranty | 12 months |
* Characteristics, delivery and appearance of the product may differ from those indicated and / or may be changed by the manufacturer without reflection of the product in the card.
