Power Supply Partizan AC220B-DC12В/ 1А (1333) GAMEMAX 450W (GM-450) Стандарт БП - ATX 12V v2.3, Мощность - 450Вт, Модуль PFC - активный, Подключение материнской платы - 20+4 pin, Подключение видеокарты - 1x6 pin, Количество разъемов SATA - 2, Количество разъемов Peripheral - 2, Тип охлаждения - вентилятор, Диаметр вентиляторов - 1x120 мм FSP 850W HYDRO PTM+ (HPT850M)
Form Factor: ATX
Power: 850W
Specification: ATX 12V V2.4
EPS 12V V2.92
Module PFC: active
80 PLUS certification: Platinum
Efficiency (max.): 92%
Motherboard power: 20+4 pin
CPU power : 2× 4+4 pin
Power supply for 6+2-pin video cards (PCIe): 8
Power supply for video cards 12-pin (PCIe): —
Power supply for video cards 16-pin (PCIe) ): —
SATA connectors: 12
Molex connectors: 4
FDD connectors: 1
Line current +3.3 V: 20 A
+5 V line current: 20 A
+12 V line current 1: 70.83 A
-12 V line current: 0.3 A
Line current +5V Standby: 3A
Power supply cooling: 135mm fan
Protection: OCP (overcurrent)
OPP (overload) power)
OTP (overheat protection)
OVP (overvoltage protection)
SCP (short circuit protection)
Cabling: modular
Backlight: RGB
Weight: 2.9 kg
Type of delivery : Retail
Power: 850W
Specification: ATX 12V V2.4
EPS 12V V2.92
Module PFC: active
80 PLUS certification: Platinum
Efficiency (max.): 92%
Motherboard power: 20+4 pin
CPU power : 2× 4+4 pin
Power supply for 6+2-pin video cards (PCIe): 8
Power supply for video cards 12-pin (PCIe): —
Power supply for video cards 16-pin (PCIe) ): —
SATA connectors: 12
Molex connectors: 4
FDD connectors: 1
Line current +3.3 V: 20 A
+5 V line current: 20 A
+12 V line current 1: 70.83 A
-12 V line current: 0.3 A
Line current +5V Standby: 3A
Power supply cooling: 135mm fan
Protection: OCP (overcurrent)
OPP (overload) power)
OTP (overheat protection)
OVP (overvoltage protection)
SCP (short circuit protection)
Cabling: modular
Backlight: RGB
Weight: 2.9 kg
Type of delivery : Retail
| В наявності | Так |
| Main characteristics | |
| Type of | Power Supply |
| Manufacturer | FSP |
| Form factor | ATX |
| Power, W | 850 |
| 80 PLUS certificate | 80 PLUS Platinum |
| Cable type | Modular |
| Motherboard power | 20+4 pin |
| CPU power | 2 x 4 + 4 |
| Video card power | 8 x 6 + 2 pin |
| Molex connectors, pcs | 4 |
| SATA connectors, pcs | 12 |
| Cooling system | 1 x fan (135 mm) |
| Weight of packing | 9 kg |
| Warranty | |
| Warranty | 36 months |
* Characteristics, delivery and appearance of the product may differ from those indicated and / or may be changed by the manufacturer without reflection of the product in the card.
